Triumph Speed Triple RS User Manual

General Information
70
Seats
Note:
• The passenger seat must be re-
moved to access the rider’s seat for
removal.
Seat Care
Caution
To prevent damage to the seat or seat
cover, care must be taken not to drop
the seat.
Do not lean the seat against the mo-
torcycle or any surface which may
damage the seat or seat cover. In-
stead, place the seat, with the seat
cover facing upwards, on a clean, flat
surface which is covered with a soft
cloth.
Do not place any item on the seat
which may cause damage or staining
to the seat cover.
For seat cleaning information, see
page 148.
Seat Lock
The seat lock is located on the left hand
side of the motorcycle, on the frame be-
low the seat.
1
1. Seat lock
Passenger Seat Removal
To remove the passenger seat:
• Insert the ignition key into the seat
lock and turn it anticlockwise while
pressing down on the front part of
the passenger seat. This will re-
lease the seat from its lock.
• Lift the front of the seat and slide
forwards for complete removal from
the motorcycle.
Passenger Seat Installation
Note:
• The rider’s seat must be correctly
installed before attempting to in-
stall the passenger seat.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
