Triumph Speed Triple RS User Manual

Maintenance
126
Compression Damping Adjustment -
Speed Triple RS
The compression damping adjuster is
accessible from the left hand side of the
motorcycle. It is coloured gold and is sit-
uated close to the rear suspension
reservoir.
1
1. Compression damping adjuster
To adjust the rebound damping setting:
• Rotate the adjuster clockwise to in-
crease rebound damping and
anticlockwise to decrease.
• Always count the number of clicks
anticlockwise from the fully clock-
wise position noting that the first
stop (click position) is counted as
zero.
Note:
• The motorcycle is delivered from
the factory with the rebound ad-
juster set at 19 clicks from the fully
clockwise position.
Spring Preload - All Models
Warning
The rear suspension unit spring
preload is not rider adjustable.
Any attempt to adjust the spring
preload could result in a dangerous
riding condition leading to loss of con-
trol and an accident.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
