Triumph Speed Triple RS User Manual

General Information
71
To install the passenger seat:
• Position the rear of the passenger
seat to the rear locator in the rear
subframe.
1
23
1. Passenger seat
2. Rear locator
3. Seat lock hook
• Locate the seat lock hook into the
lock plate assembly and press down
to engage it in the lock. An audible
click can be heard when the seat is
correctly engaged in the lock.
Warning
To prevent detachment of the seat
during riding, after fitting always grasp
the seat and pull firmly upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat could cause
loss of motorcycle control and an acci-
dent.
Rider’s Seat Removal
Note:
• The passenger seat must be re-
moved before attempting to remove
the rider’s seat.
To detach the rider’s seat:
• Remove the passenger seat as de-
scribed on page 70.
• A tool is located at the rear of the
passenger seat. Using the tool, re-
move the two fixings securing the
rider’s seat to the lock plate.
21
2
1. Rider’s seat
2. Fixings
• Slide the seat rearwards and lift
the rear of the seat.
• Disengage the locators from the
frame, and the front bracket from
below the fuel tank hinge.

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
