Maintenance
122
Front Suspension Adjustment
Spring Preload Adjustment -
All Models
The spring preload adjusters are located
at the top of each fork.
1
1. Speed Triple S spring preload adjuster
1
1. Speed Triple RS spring preload adjust-
ers
To change the spring preload:
Rotate the adjuster clockwise to in-
crease preload, or anticlockwise to
decrease preload.
Always count the number of clock-
wise turns from the fully
anticlockwise position and set both
forks to the same settings.
Note:
The Speed Triple S is delivered from
the factory with the spring preload
set at 7.5 clockwise turns from the
fully anticlockwise position.
The Speed Triple RS is delivered
from the factory with the spring
preload set at 8.5 clockwise turns
from the fully anticlockwise posi-
tion.
Rebound Damping Adjustment -
Speed Triple S
The rebound damping adjuster is locat-
ed at the top of each fork.
1
1. Rebound damping adjuster
