Triumph Speed Triple RS User Manual

Maintenance
106
• Release the three fixings and re-
move the front panel from the fuel
tank.
21
2
2
1. Front panel
2. Fixings
• Remove the front fixings for the
fuel tank.
ckfq
1
2
1. Fuel tank
2. Fixings
• Pivot the fuel tank upwards at the
front. While holding the fuel tank in
the raised position, locate the fuel
tank support into the support
points on the air box and the fuel
tank.
3
1
2
4
1. Fuel tank support
2. Fuel tank
3. Supporting point, fuel tank
4. Supporting point, air box
Lowering the Fuel Tank
To lower the fuel tank:
• While holding the fuel tank, remove
the fuel tank support and lower the
fuel tank. Refit the front fixings and
tighten to 4 Nm.
• Refit the front panel and tighten
the fixings to 2 Nm.
• Securely fit the fuel tank support to
its location on the seat.
• Refit the seat (see page 70).

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
