20
Display Navigation
The table below describes the instru-
ment icons and buttons used to
navigate through the instrument menus
described in this handbook.
Home button (right hand
switch housing).
m
Mode button (left hand switch
housing).
Joystick left/right or up/down.
Joystick Centre (press).
Selection arrow (right shown).
Information Tray - left/right
scroll via joystick.
Information Tray - up/down
scroll via joystick.
Option available within the In-
formation Tray - scroll via
joystick up/down.
Short press (press and re-
lease) via joystick centre.
Long press (press and hold)
via joystick centre.
Reset current feature, (only
available with joystick long
press).
Themes and Styles
There is the option to change the style
of the instrument display.
Depending on the motorcycle model,
there are either one or two themes.
Each theme has three different styles to
select from.
To select a theme or style, see page 44.
Styles can also be selected through the
Style Options tray, see page 35.
Theme 1, Style 1 is used for visual recog-
nition throughout this owner’s
handbook.
Theme 1
12
14
25.2
F
E
TRIP
mi mp/hHH:MM
PM
RPM
x1000
10
Theme 1 Style 1
Warning Lights
Note:
• When the ignition is switched on,
the instrument warning lights will
illuminate for 1.5 seconds and will
then go off (except those which re-
main on until the engine starts, as
described in the following pages).
For additional warning and information
messages, see page 32.
