32
The information tray contains the fol-
lowing information tray items:
• Warnings and Information
Messages, see page 32
• Fuel Information, see page 32
• Tyre Pressure Monitoring System
(TPMS) (if fitted), see page 64
• Odometer, see page 34
• Service Interval Announcement, see
page 34
• Screen Contrast, see page 34
• Style Options, see page 35
• Coolant Temperature, see page 35
• Trip Meter, see page 35.
Different information tray items can be
shown or hidden from the information
tray. For further information, refer to
page 45.
Warnings
Any warnings and information messages
are shown in the Warnings tray. An ex-
ample is shown below.
12
14
F
E
PM
RPM
x1000
10
mph
LOW BATTERY
CHECK MANUAL
1/2 warnings
1 3
1
2
1. Low battery warning
2. Warning counter
3. Warning description
To view the warnings:
• Push the joystick left/right to scroll
through the options until the warn-
ing review is shown.
• Push the joystick down/up to re-
view each warning (if more than
one). The warning counter will show
the amount of warnings that are
present.
• Push the joystick left/right to re-
turn to the information tray.
Low Battery Warning
If items such as heated grips are fitted
and are on with the engine at idle, over
a period of time, the battery voltage
may drop below a predetermined volt-
age and a warning message will be
shown in the Warnings tray.
Fuel Status Information
The Fuel Status information tray shows
fuel consumption information.
59 42 12
MPG MPG
RANGE
1. Fuel information light
2. Average fuel consumption
3. Instantaneous fuel consumption
4. Range to empty
5. Reset
Fuel Information Light
This light illuminates when the fuel level
warning light is activated.
