Triumph Speed Triple RS User Manual

Parts Identification
14
Rider View Parts Identification
4 32 5 6
8
11
1
12
9
14
7
10 13 15 16
1. Clutch lever
2. High beam button
3. Daytime Running Lights (DRL) switch
(if fitted)
4. Cruise control
5. Instrument display
6. Front brake fluid reservoir
7. Hazard button
8. Steering lock button (Speed Triple RS
only)
9. Front brake lever
10. Horn button
11. Direction indicator switch
12. Joystick button
13. MODE button
14. Ignition switch (Speed Triple S only)
15. HOME button
16. Engine start/stop switch

Triumph Speed Triple RS Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	1160 cc
Max Torque	125 Nm @ 9, 000 rpm
Transmission	6-speed
Seat Height	830 mm
Weight	198 kg (wet)
Max Power	180 PS (132.4 kW) @ 10, 750 rpm
Rear Suspension	Ohlins TTX36 twin tube monoshock, fully adjustable
Front Brakes	Brembo Stylema, 320 mm twin disc
Rear Brakes	Brembo single piston caliper, single 220 mm disc
Fuel Tank Capacity	15.5 litres
Front Suspension	Öhlins 43mm NIX30 upside down forks, fully adjustable
