30
Note:
• The riding mode will default to
ROAD when the ignition is switched
on, if the RIDER mode was active
the last time the ignition was
switched off with ABS or TC set to
OFF in either of those modes.
• Otherwise, the last selected riding
mode will be remembered and acti-
vated when the ignition is switched
on.
• If the mode icons are not shown
when the ignition is switched on,
then make sure that the engine
stop switch is in the RUN position.
The current riding mode is shown in the
upper left of the display screen.
To select a riding mode:
• Press and release the MODE button
on the left hand switch housing to
activate the riding mode selection
tray at the bottom of the display
screen.
• The currently active riding mode
icon is highlighted with a blue back-
ground.
To change the selected riding mode:
• Either push the joystick left or
right, or repeatedly press the MODE
button until the required mode is in
the centre of the display screen,
highlighted with an arrow above it.
• A brief press of the joystick centre
will select the required riding mode,
and the icon in the upper left of the
display screen will change.
12
14
F
E
PM
RPM
x1000
mph
m
10
4
3
3
1
2
1. MODE button
2. Joystick
3. Current riding mode
4. New riding mode
• Push the joystick left/right or press
the MODE button to scroll through
the riding mode options in the fol-
lowing order:
– RIDER
– RAIN
– ROAD
– SPORT
– TRACK (Speed Triple RS only).
The selected mode is activated once the
following conditions for switching modes
have been met:
Motorcycle Stationary - Engine Off
• The ignition is switched on
• The engine stop switch is in the
RUN position.
