Instruction Manual Page 17
Revision 7/06.12 of 63
 N – power wire “Null”;
 Ground - safety ground wire.
The cable shall be double insulated and of 0,5mm
2
section for the power supply wires, and of
1,5mm
2
section for the safety ground wire.
The other end of the feeding cable is connected to the mains power supply by means of junction
box.
The mains power supply of the fire control panel shall be in a separate loop.
5. General information
5.1. Access levels
4 levels of access to the variable indications and control functions of FS5200Е are available.
5.1.1. Access level 1
All persons who would presumably find out and react to alarm upon fire condition or fault
condition have access to level 1.
The following actions are accessible:
 Displaying suppressed messages for Fire condition stage I, Fire Condition stage II, Fault
condition, Disabled components;
 Forced proceeding from phase Fire condition stage I to phase Fire condition stage II ;
 Suppressing the local sounder;
 Displaying the status of the lines and the monitored outputs (see section 12.5);
All light indicators are visible.
5.1.2. Access level 2
The personnel in charge of the fire protection have access to level 2; they shall be trained and
authorized to operate the fire control panel in the following conditions:
 Duty Mode;
 Fire condition stage I;
 Fire condition stage II;
 Fault condition;
 Disabled component;
 Information and adjustment.
To enter Access level 2, turn the key on the front panel of the fire extinguishing control panel into
position .
The following features of the fire extinguishing control panel are accessible:
 All features accessible at Level 1;
 Switching off the outputs, activated upon fire condition;
 Exit of Fire condition;
 System functions of the fire extinguishing control panel except entering Set up Mode
(see section Error! Reference source not found.).
5.1.3. Access level 3
Accessible for personnel trained and authorized for:
 Reconfiguration of specific data – of the protected site or of the fire extinguishing control
panel – saved in the memory;
 Maintenance of the fire control panel.
This level has two sublevels of access - 3A and 3B.
Level 3, sublevel 3A, is accessed through a password entered at Access level 2. At this
sublevel the functions for reconfiguration of specific data for the protected site or the fire extinguishing
control panel are accessible.
Level 3, sublevel 3B is accessed when the fire extinguishing control panel is opened. The
following features are accessible:
 Replacing a burnt fuse;
 Adding, removing or replacing a module;
 Connecting fire detecting lines and executive devices.
