UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 6
Revision 7/06.12 of 63
b) Manual button release for forced extinguishing.
The indication for Fire condition stage 1 is common light indication. Local sound signaling and
text messages on the LCD display.
INTERRUPTED LINE, MONITORED OUTPUT OR MONITORED INPUT non-system non-fatal
fault condition entered when parameters lower than the threshold value are registered.
RELAY OUTPUT a relay, potential-free switching outputs provided for controlling external
executive devices.
MANUAL RELEASE condition entered by the fire extinguishing control panel in the event of
Fire condition stage II, regardless the status of the Fire detecting lines. The manual release is defined
by “on” status of the monitored input „Manual Release”.
MANUAL MODE condition when the fire extinguishing control panel could release the
extinguishing devices only by manual release command. The manual mode is defined by “on” status
of the monitored input „Mode Select”. The mode indication is an individual light indication.
SYSTEM FAULT CONDITION fault condition due to a fault in the fire extinguishing control
panel (system’s) component panel. The system fault condition could be fatal or non-fatal. The
indication is common light indication, local sound indication and text messages on the LCD display.
REMOVED FIRE DETECTOR /FD/ non-system non-fatal fault condition entered when a
removed fire detector in a line is registered. In order this function to be utilized follow the special
diagram for connection (See section 5.2.).
LINE STATUS, MONITORED OUTPUT OR MONITORED INPUT the current status of a line,
monitored output or input: duty mode; fire condition (only for the fire detecting lines); fault condition
(specifying the type of the fault condition).
FATAL FAULT CONDITION fault condition that prevents the fire extinguishing control panel, or
the part of it related to the communication with the user, from continuing its operation. The fatal fault
condition is usually a system one, except Law Battery fault condition. The indication is common light
indication, local sound indication and text messages on the LCD display.
2. Technical data
Fire detecting lines
For extinguishing control - 2
Without extinguishing control - 1
Maximum number of fire detectors in a line - 32
Type of the connecting line - two-wire
Maximum resistance of a loop - 100
Output resistance of the line - 164
2.1. Current thresholds in a line per default parameters for:
3mA* - interruption
3÷12mA* - duty mode
12÷60mA* - fire condition
>80mA - short circuit
* It is possible the current in the lines for interruption, duty mode and fire condition to be
adjusted (13.4.2.1.).
2.2. Monitored outputs for control the fire extinguishing control panel performance:
