UniPOS FS5200E User Manual

UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 7
Revision 7/06.12 of 63
 Type - balanced
2.3. Monitored outputs for the sound-light indication
 Type - potential relay
 Electrical characteristics - (24±3)V/0.5 A
2.4. Monitored output for the extinguishing devices
 Type - potential relay
 Electrical characteristics - (24±3)V/1.5A
2.5. Relay outputs for common purpose
 Type - potential free, switching
 Electrical characteristics - 3A/125VAC; 3A/30VDC
2.6. Relay output for fault condition
 Type - potential free, switching
 Electrical characteristics - 3A/125VAC; 3A/30VDC
2.7. Relay output for fire alarm
 Type - potential free, switching
 Electrical characteristics - 3A/125VAC; 3A/30VDC
2.8. Performance characteristics
 Control over the lines, the monitored inputs and outputs for fault condition (short circuit
and interruption) and automatic reset
 Control over the lines for removed fire detector and automatic reset
 Ability to set the evacuation time
 Ability to set the time when the extinguishing executive device is switched on
 Built-in sounder for fire alarm first stage – one tonal, discontinuous, can be switched off
 Built-in sounder for fire alarm second stage – one tonal, continuous, can be switched off
 Built-in sounder for fault condition – one tonal, discontinuous, can be switched off
 Built-in real time clock
 Set of test modes and options for adjustment:
 Setting the clock;
 Check ups on light and sound indications;
 Test of the fire detecting lines;
 Adjustment of outputs and integrated external devices;
 Current measurement in the fire detecting lines;
 Programming of parameters and modes of operation;
 Remote programming of the parameters from distant operator control point;
 Energy independent archive of registered events by the fire extinguishing control panel
with the events type, date and hour – up to 100 events;
 Interfaces for communication with external devices - RS-485 and CAN 2.0
2.9. Indications of registered events
 Light indication - LED
 Text message - LED display -
4 lines 20 characters per line,
Cyrillic, backlit
 Sound signaling - built-in sounder
2.10. Power supply
2.10.1. Mains
 voltage - 220/230V
 frequency - 50/60Hz
2.10.2. Back up batteries
 battery type - led, gel electrolyte
 number of batteries - 2 pcs
 connection - serial connection
