UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 31
Revision 7/06.12 of 63
12. Information and Control Mode
12.1. Description
Information and Control Mode provides the user with the possibilities to display information
associated with the settings of the fire extinguishing control panel, and to enter control data.
The operation in this mode could be in combination with the following modes of the fire
extinguishing control panel:
- Duty Mode;
- Fire condition Stage I;
- Fire condition Stage II;
- Disabled component;
- Test;
- Fault condition
- Setup.
12.2. Indication
12.2.1. LED and sound indication
No specific LEDs or sound indication is provided for this Mode.
12.2.2. Text messages
The screens visualized on the display are organized in a tree structure, containing subordinate
menus (Appendix 2).
Information and Control Mode shows information in the first two lines of the display that are used
by Fire condition as a text field to indicate the first line in which the fire extinguishing control panel has
entered in fire condition.
Each screen has specific text message referring the operations that are performed in it. The
specific text messages are described for the respective screens. .
12.3. Using the keypad
Press the button to enter Information and Control Mode from the screens of Duty Mode,
Fire condition, Fault condition, Test Mode and Disabled Component, thus their text messages are
suppressed. Where the fire extinguishing control panel operates in combination of Information and
Control Mode and Fault Condition, button (Alarm) is active too. Where the fire extinguishing
control panel operates in combination of Information and Control Mode and Fire Condition, buttons
(Alarm) and (Outputs) are active.
Transition to a lower hierarchy menu is performed by the means of button ; to revert to an
upper hierarchy menu use button . To switch between elements of one menu use buttons
and .
The screens containing specific information (information screens) or providing the possibility for
changing the parameters and executing the commands (command screens) are at the lowest level.
The button is not active with the information screens as the other three buttons keep their
functions. A cursor appears when a screen for changing a parameter or a command screen is
activated. In this case the buttons has the following action:
 press the button to save the changed parameter or to execute the selected command,
then the screen is deactivated and the cursor disappears (the different operation of the button
in some cases are specifically pointed);
 press the button to deactivate the screen without saving the changed parameter or
without executing the respective command, and the cursor disappears;
