UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 8
Revision 7/06.12 of 63
nominal voltage of the back up battery - 2x12V
nominal capacity C
20
- (7-12)Ah
extreme discharge voltage - 21V
charge voltage - 28,2V
2.10.3. Consumption on back up batteries supply
At 24V - < 120mA
2.10.4. Power supply to external devices
Voltage - (24±3)V
Maximum current value (including current
of monitored outputs ) - 2,5А
2.11. Dimensions
Overall dimensions - 450х355х115mm
2.12. Weight
weight (batteries not included), maximum - 6,6kg
3. Contents of delivery
3.1. Fire extinguishing control panel
Fire detecting control panel FS5200Е - 1 pc.
Resistors 3,0k/ 0,25W - 11 pcs.
Resistors 1,5k/ 0,25W - 5 pcs.
Diode 1N4004 - 1 pc.
Jumper for the back up batteries - 1 pc.
Fuse 4A - 2 pcs.
CD (Instruction manual,Operator’s manual) - 1 pc.
Packing - 1 pc.
4. Installation and arrangements
When fire detectors and periphery devices are integrated in the fire extinguishing control panel,
avoid arranging wires in closed loops; it will reduce the control panel’s resistance to electro magnetic
interferences.
4.1. To mount the control panel
unpack the control panel;
put the dowels on the determined places for fixing the control panel;
fasten the control panel to the dowels through the three holes provided on the chassis.
4.2. Description of inputs and outputs. Periphery devices assembly to the control panel.
All connections are to be made by means of terminals, mounted on the printed circuit board. Be
advised, that the total consumption of the voltage powering the external devices (terminal “+ 28V”)
plus the consumption of the monitored outputs shall not exceed 2.5A in heavy duty mode.
“L1”, “L2” – Inputs for switching automatic Fire detectors. In Fire condition an
extinguishing procedure starts along both lines according to set up algorithm.
“L3” – Fire detecting line input.
“Manual Release” – Input with line status monitoring. The input sends a signal to the
control panel from a manual button to start the extinguishing procedure.
“Mode Select” - Input with line status monitoring. The input sends a signal to the control
panel from a switch for the operating mode. The modes are Manual-Automatic and Manual.
“Hold” - Input with line status monitoring. The input sends a signal to the control panel
