UniPOS FS5200E User Manual

UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 9
Revision 7/06.12 of 63
from a manual button or controlled contact for holding (delaying) the extinguishing
procedure.
 “On/Off Exting” - Input with line status monitoring. The input sends a signal to the control
panel from a switch for disabling the extinguishing procedure.
 “Low Press” - Input with line status monitoring. The input sends a signal to the control
panel from pressostat contact, balance or other device to show the extinguishing agents
draining.
 “GND” – Terminal for sending GND potential to the periphery devices.
 “Еxting” – Active level output with line status monitoring. The output switches the
extinguishing automation valves on.
 “S2 Sounder” – Active level output with line status monitoring. The output switches the
sound-light indication on in Fire condition stage II.
 “S1 Sounder” – Active level output with line status monitoring. The output switches the
sound-light indication on in Fire condition stage I.
 “Rele Fire” – Output, relay, potential free, the line status is not monitored. The output
controls the devices in Fire condition of the control panel, registered by the fire detecting
lines.
 “Rel Fault” – Output, relay, potential free, the line status is not monitored. The output
controls the devices in Fault condition of the control panel.
 “+28V” – Three terminals for supplying 28V voltage to the periphery devices as well as the
positive potential of the open collectors OK1, OK2 and OK3.
 “OK1” – Output open collector /in active status it supplies GND potential, in non-active
status it has potential +28V via resistor 47k/0.125W/. The output controls relays, LEDs and
other devices, with total consumption not exceeding 100mA. The output is active when the
control panel has registered extinguishing reagent leakage.
 “OK2” – Output open collector /in active status it supplies GND potential, in non-active
status it has potential +28V via resistor 47k/0.125W/. The output controls relays, LEDs and
other devices, with total consumption not exceeding 100mA. The output is active when the
control panel is in Disable Extinguishing Mode.
 “OK3” – Output open collector /in active status it supplies GND potential, in non-active
status it has potential +28V via resistor 1k/0.125W/. The output controls relays, LEDs and
other devices, with total consumption not exceeding 100mA. The output is active when the
control panel is in manual Mode.
 “Rel 2ST” – Output, relay, potential free, the line status is not monitored. The output
controls the devices in Fire condition stage II of the control panel.
 “Rel 1ST” – Output, relay, potential free, the line status is not monitored. The output
controls the devices in Fire condition stage I of the control panel.
 “CAN” – Terminals to connect the two-wire line of CAN interface. The connection with the
Interactive system IFS7002 /production of UniPOS LTD/ is executed via this interface. A
jumper is provided that shunts the line by 120 ohms. It is needed if the fire extinguishing
control panel is the final point in the interface line. The interface requires resistors 120
ohms to be mounted in both ends of the line.
 “RS 485” – Terminals to connect the two-wire line of RS 485 interface. The connection
with a repeater, PC and other devices realized by exchange protocol - UniProtocol
/FS5200E interface/ is executed via this interface. As the case with CAN interface, a
jumper is provided here too with the same functions.
 “┴” – Terminal to connect a third wire /screen/ of the interfaces cable.

UniPOS FS5200E Specifications

General

Brand	UniPOS
Model	FS5200E
Category	Control Panel
Language	English
