UniPOS FS5200E - Using the Keypad

UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 28
Revision 7/06.12 of 63
 Faults in monitored outputs:
(The field “ЕEЕ” shows the number of the faults;
The field “Status” shows the monitored output
status, i.e. the type of the fault)
 Fault in the mains supply:
(The field “ЕEЕ” shows the number of the faults).
In this case the display illumination is off. To turn it
on press the button. 20s after the last pressing of
the button it is off again.
 Fault in backup battery supply:
(The field “ЕEЕ” shows the number of the faults).
 Fault in the power supply of external devices –
activated fuse:
(The field “ЕEЕ” shows the number of the faults).
 Short circuit to grounded wire:
(The field “ЕEЕ” shows the number of the faults).
 Fault in the negative supply:
(The field “ЕEЕ” shows the number of the faults).
When the fire extinguishing control panel is in Fire condition, the fault messages are suppressed.
The suppressed messages could be seen in Information and Control Mode.
Upon fault in the Fire detecting line, the type of fault could be seen in the individual field of the
respective line, as the abbreviations mean:
„Sho” – Fault - Short circuit;
„Int” – Fault – interruption;
„ReD” – Fault – Removed fire detector.
9.3. Using the keypad
None of the buttons is active upon fatal fault condition (except for New Configuration).
For all other fault condition 2 buttons are being supported. Where the fire extinguishing control
panel operates in combination of other conditions, their buttons are active too.
Button
Access
level
Operation
Additional information
Button
(Alarm)
all
Press it to:
- suppress the local sounder;
- activate the local sounder if
the fire extinguishing control
panel is in Fire condition or
Fault condition and the local
sounder has been
suppressed by previous
The button operation is
reversive i.e. press it once to
change the current condition
alternatively – suppressed or
activated local sounder.
The LED indicator illuminates
if the active condition of the
local sounder is suppressed.
Duty 17:05:34
Fault:ЕEЕ FltPower -5V
L1:Dut.L2:Dut.L3:Dut
Duty 17:05:34
Fault:ЕEЕ Fault Earth
L1:Dut.L2:Dut.L3:Dut
Duty 17:05:34
Fault:ЕEЕ FltPower 28V
L1:Dut.L2:Dut.L3:Dut
Duty 17:05:34
Fault:ЕEЕ Flt Battery
L1:Dut.L2:Dut.L3:Dut
Duty 17:05:34
Fault:ЕEЕ Flt Mn Power
L1:Dut.L2:Dut.L3:Dut
Duty 17:05:34
Fault:ЕEЕ MONN Status
L1:Dut.L2:Dut.L3:Dut
