UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 4
Revision 7/06.12 of 63
Introduction
The fire extinguishing control panel FS5200Е is designated for fire protection, monitoring and
control of systems for active extinguishing.
After processing the signals from the automatic fire detectors and/or manual call points the control
panel it sends commands to the executive devices for extinguishing, sound-light signalers, air
conditioning and ventilation devices, it sends information to a repeater, PC or another intelligent
devices.
FS5200Еcould be used in – gas, powder, aerosol, water and other types of systems for active
extinguishing.
The fire extinguishing control panel is designed for extinguishing in one zone. It is possible up to
15 zones to be protected when the fire extinguishing control panel is connected in a network via
interface RS485 and a repeater FS5200R.
The fire extinguishing control panel could be connected and become a part of the Interactive Fire
Control System IFS7002 /UniPOS production/.
The fire extinguishing control panel FS5200Е is designed and produced in compliance with
standards EN 54-2:1997/ А1:2006/AC: 2009, EN 54-4:1997/A2: 2006/AC: 2009, EN 12094-1: 2003.
Some of its main features and possibilities are:
 adjustment of operating modes and parameters of each fire alarm line, output and input via
built in keypad;
 user oriented menu dialogue for easy and convenient operation;
 LCD for visualization of system checkup and set up modes;
 LEDs indication for early warning of a break down or extreme conditions;
 energy independent archive memory saving the event type, date and time, allowing for
detailed analysis of the actions of the authorized personnel and of possible problems in the
fire protection process of the area;
 user oriented test modes allowing for a total control of the site protected;
 built-in serial interface RS485 and CAN for connection to other fire control panels;
 compatible to random installation design, within the range of the available fire extinguishing
control panels resources.
All these are realizable via fire extinguishing control panel’s keypad and after a detailed
examination of the instructions set herewith.
1. Terminology
OUTPUT – monitored or relay output, programmed by the user to be activated during the different
stages of the extinguishing.
EVACUATION TIME – the time from occurring the situation for extinguishing to the moment of
switching on the extinguishing automatics. This time should be enough for the evacuation of the staff
from the premises. The evacuation time is user defined for the specific site. The evacuation time is
shown on the LCD display and it counts down the remaining time until the release of the extinguishing
automatics.
DISABLED LINE – the fire detecting line is switched off (not power supplied) and it is not
monitored for turned out fire detector and a fault condition. This feature is user defined. The indication
for a disabled line is common light indication and text messages on the LCD display.
DISABLED OUTPUT – the output is switched off (the executive device can not be activated) and
is not monitored for a fault condition in the monitored outputs. This feature is user defined. The
indication for a disabled monitored output is common light indication and text messages on the LCD
display.
DISABLE EXTINGUISHING – condition of the fire extinguishing control panel when regardless
the input actions the executive extinguishing device cannot be activated. Disable extinguishing is
