UniPOS Fire Extinguishing Control Panel FS5200Е
Instruction Manual Page 45
Revision 7/06.12 of 63
Transition to a lower hierarchy menu is performed by the means of button ; to revert to an
upper hierarchy menu use button . To switch between elements of one menu use buttons
and .
The screens containing specific information (information screens) or providing the possibility for
changing the parameters and executing the commands (command screens) are at the lowest level.
The button is not active with the information screens as the other three buttons keep their
functions. A cursor appears when a screen for changing a parameter or a command screen is
activated. In this case the buttons has the following action:
press the button to save the changed parameter or to execute the selected command,
then the screen is deactivated and the cursor disappears (the different operation of the button
in some cases are specifically pointed);
press the button to deactivate the screen without saving the changed parameter or
without executing the respective command, and the cursor disappears;
button is active only in the screens for changing the parameter. Press it to:
move the cursor one position to the right. Upon reaching the last position of the parameter
the cursor returns to the first one;
decrease the parameter to the next possible value. Upon reaching the minimal possible
value it turns to the maximum value of the class or the parameter;
button is active only in the screens for changing the parameter. Press it to increase by
one unit the class marked by the cursor or to increase the parameter to its next possible value.
In both cases upon reaching the maximum possible value it turns to the minimum value of the
class or the parameter.
