February 2011 A-2 P/N 06-237041-001
Solenoid-Based Devices: (continued)
897494-000 (WK-897494-000) - 1.500 -
897494-530 (WK-897494-530) - 1.500 -
Marioff 3-101-46A/2 (D21070), Standard - 0.920 -
FM Solenoid (Group A) - 0.458 -
FM Solenoid (Groups B,D) - 0.700 -
FM Solenoid (Groups E,G) - 0.420 -
FM Solenoid (Group F) * - 0.92 -
FM Solenoid (Group I) * - 0.364 -
FM Solenoid (Group J) * - .42 -
FM Solenoid (Group K) * - .375 -
Initiator-Based Devices:*
Note: The firing current of “Momentary On” initiator devices will
be 2.5 A.
93-002009-004 (Momentary “On”) - - - -
31-199932-004 (Momentary “On”) - - - -
93-191001-001 (Momentary “On”) - - - -
Notification Appliances: (enter below)
PMU Auxiliary Out Use: (enter below)
ENTER TOTAL STANDBY CURRENT (Sum of column):
ENTER TOTAL ALARM CURRENT (Sum of column):
* Typical currents only. Refer to specific product information sheets.
Calculations:
REFERRING TO TABLE A-2, ENTER STANDBY TIME REQUIRED (in hours): ______
REFERRING TO TABLE A-2, ENTER ALARM TIME REQUIRED (in minutes): ______
CONVERT ALARM TIME REQUIRED TO HOURS (using formula below):
(minutes)/60 = ______hours
CALCULATE TOTAL AMPERE HOURS (using formula below):
((TOTAL STANDBY CURRENT) x (STANDBY TIME REQUIRED in hours)) + ((TOTAL ALARM CURRENT
x ALARM TIME REQUIRED in hours)) = ______TOTAL AMPERE HOURS
CALCULATE BATTERY CAPACITY WITH A DE-RATING FACTOR OF 20%
(using formula below):
1.2 x TOTAL AMPERE HOURS = ______BATTERY CAPACITY
REFERRING TO TABLES A-3 AND A-4, DETERMINE NUMBER OF POWER SUPPLIES NEEDED:
NOTE: If TOTAL ALARM CURRENT > 5.4 A, then 2 or more PSUs are required.
Table A-1. Current and Alarm Load Worksheet (Continued)
Unit Description Qty
Unit Standby
Current
(A)
Unit Alarm
Current
(A)
Total
Standby
Current
Total Alarm
Current
