Testing and Maintenance
February 2011 5-2 P/N 06-237041-001
Fenwal provides the following batteries:
Note: Other capacity (AH) batteries can be used (obtained from third party suppliers).
5-2.3 Initiating-Devices Test
The FenwalNET 8000-ML control unit automatically tests all of the initiating devices connected to the
signaling line circuit on a daily basis.
You should re-test the initiating devices by selecting on-board circuits: “RNAC1” and/or “RNAC2”
from the system menu. Refer to Figure 3-33 for menu stucture location. For initiating devices
connected to R-NAC expansion cards, refer to Figure 3-34 for menu stucture location. Investigate any
"Device-Failed" messages and replace any defective initiating devices as appropriate.
5-2.4 Walk Test
Confirm acceptable fire-signature-entry characteristics for all automatic initiating devices by selecting
“Walk Test” from the system menu. Refer to Figure 3-32 for menu stucture location. Use these menu
functions to confirm that all monitor modules are also working correctly.
5-3 MCB CLOCK BATTERY REPLACEMENT
The Main Controller Board includes an on-board Real-Time Clock with a lithium battery. The
following replacement batteries are recommended:
• Maxell CR1220
• Panasonic BR1220
• Renata CR1220 MFR
To replace the MCB clock battery:
1. Use a screwdriver or other small instrument to remove the old battery, pushing to the right side
opening.
2. Remove the old battery and discard.
3. Gently slide the replacement battery into place from the right side opening and press to secure
in the holder.
Refer to Figure 1-8 for location of the MCB Real-Time Clock Battery.
Table 5-1. Available Standby Batteries
Part Number Capacity (AH)
06-115915-013 7
06-115915-047 12
06-115915-046 17/18
89-100052-001 35
To Next Page
