Configuration and Programming
P/N 06-237041-001 3-39 February 2011
Figure 3-32. FenwalNET 8000-ML Test Menu Functions (Cont’d - Fig. 2 of 5)
FOOTNOTES (Figure 3-32):
Note: The Walk Test can only be executed on a single loop system.
2 Walk Test. Start Walk Test. Run an Audible Walk Test. Purpose: To suspend normal system
operation for functional testing of one or more SmartOne initiating devices.
The FenwalNET 8000-ML control unit will not display and act upon alarm reports from initiating
devices selected for walk testing. There is no need for the operator to acknowledge, silence, or reset
an event initiated during a walk test. The control unit will only energize outputs programmed for
walk-test activation for a period of one second following the receipt of an alarm signal from any of the
devices selected for walk testing.
Outputs programmable for walk testing include control unit-based NACs and combination circuits
configured as NACs and SLC-based output modules (such as ASMs and AOs).
The most-current walk-test results for all initiating devices are stored in the walk-test log. The walk-
test mode will automatically end after 30 minutes of inactivity. It can also be ended by a system reset
or by using the “Stop Walk Test” menu function.
4. TEST
Cont’d
*
5. Alarm Sim Test
Alarm Simulation Test
Enter SLC Address *__ (1-255)
1. Activate 2. Deactivate
1. Start Device Walk Test
SLC Devices From *__ to ___
(1-255)
2. Stop Walk Test
3. Start Device Silent Walk Test
SLC Devices From *__ to ___
(1-255)
*=
Level-2 (Installer) Password required .
2
4
3
5
SLC Module Selection
Enter SLC Module Number (1-8)__
1. Start Walk Test 2. Stop Walk Test
3. Silent Walk Test
SLC Module Selection
Enter SLC Module Number (1-8)__
*
4. Walk Test
2
1. SLC Alarm Sim 2. HSD Alarm Sim
SLC Loop Selection
Enter SLC Loop Number (1-8)__
5
5
2. HSD
