UTC Fire and Security FenwalNET 8000-ML User Manual

Installation
P/N 06-237041-001 2-21 February 2011
2-6 MAKING INTERNAL COMMUNICATION CONNECTIONS
Figure 2-17 provides an overview of internal communication connections for the FenwalNET 8000-
ML system.
Figure 2-17. Internal Communication Connections
-V 12-
Card Cage Backplane Additional Card Cage Backplane
PMU Board
Main Controller Board
Additional
PMU Board
To next Backplane or for Termination Plug
J10 J11
J10 J11
J12 J13
J12 J13
RS232 Ports
J9
J2
J12
To next Backplane or for Termination Plug
USB Ports
