Configuration and Programming
P/N 06-237041-001 3-1 February 2011
CHAPTER 3
CONFIGURATION AND PROGRAMMING
3-1 INTRODUCTION
This chapter provides instructions on how to initialize an installed FenwalNET
8000-ML
TM
system,
set up password protection and program all configurable options in the menu system to make the
system ready for Normal Operation.
The FenwalNET 8000-ML System uses field-programmable software. An overview of the system
menus (accessible from the Keypad/Display) and instructions on how to program the FenwalNET
8000-ML are provided in this chapter.
Refer to the FenwalNET 8000-ML Configuration Software User’s Guide, P/N 06-237042-001, for
instructions on how to program the FenwalNET 8000-ML System from a PC or laptop. Refer also to
the Operating Instructions, P/N 06-237048-001, that are packaged with the FenwalNET 8000-ML
system.
3-1.1 Initial Signaling-Line Circuit Configuration
Note: The following procedure assumes that all SmartOne devices have been addressed with the
Handheld Programmer or via the FenwalNET 8000-ML keypad. Refer to the instructions
provided with the Handheld Programmer to address SmartOne devices using this
programmer.
Note: On the FenwalNET 8000-ML keypad, the BACKSPACE key () is located directly above the
ENTER key (
). In these instructions, the ENTER key is represented by its symbol:
Use this procedure to initially configure and check the number of SmartOne devices connected to the
SLC.
1. Connect the wiring to each SLC to the applicable Terminal Block. Refer to Figure 2-24 and
Figure 2-25 for typical SLC wiring.
2. Power the control unit, and set the time and date, by using the menu as depicted in this chapter.
3. All of the SmartOne devices connected to the SLC will report a not-registered trouble message
similar to the message shown in Figure 3-1:
Figure 3-1. Typical Device Not Registered Message
4. Wait for all of the device-not-registered troubles to report. Press the <ACKNOWLEDGE> Key one
or more times to silence the control unit buzzer.
5. Confirm that no more trouble messages have been reported.
6. Record the number of currently-active troubles. The number of troubles should be equal to the
number of SmartOne devices connected to the SLC.
7. Run the AutoLearn Routine as follows:
L3:025 NOT REGISTERED ON UNKNOWN TYPE
DISCHARGE-00 CNTDN-00 ABT-00 ALM-00
PREALM-00 AV CNTDN-00 SPV-000 TBL-001
Trouble Not-Registered Indication
Device Type Not Known
at This Time
Device
Address
Number
025
Panel Status
SLC Loop
Number 3
To Next Page
