Configuration and Programming
February 2011 3-2 P/N 06-237041-001
a. Press the 0 Key. This display will show this message:
Figure 3-2. Password Prompt
b. Enter the default Level-2 Password keys (186591) and then press
 The top-level menu
selections will be displayed:
Figure 3-3. Top-Level Menu Selections
c. Press the 3 Key to select "SET"
Figure 3-4. Set Menu
d. Press the 4 Key to select "PROGRAMMING".
e. Press 3 to select “AUTOLEARN”
Figure 3-5. Programming Sub-Menu
Figure 3-6 shows a typical message that displays when the AutoLearn routine is
running.
Figure 3-6. Typical Auto-Learn In-Process Display
The AutoLearn Routine will register and assign a default operating configuration to
each device on the SLC. Refer to Footnote #26 of Figure 3-24 for a detailed
description of the AutoLearn Routine.
f. The control unit will display the following message when the AutoLearn Routine is
finished.
Figure 3-7. Typical Auto-Learn Complete Display
g. Press the <Backspace> Key as required to exit from the menu operating mode. The
message “Initializing Configuration” will appear, followed by “System Must Restart”.
h. The control unit will restart in order to begin to use the new settings. Confirm that no
new trouble messages have appeared on the display.
The FenwalNET 8000-ML control unit is now ready for site-specific programming.
PLEASE ENTER PASSWORD
******
1: ISOLATE 2: LIST
3: SET 4: TEST
1: TIME/DATE 2: PORT CONTROL
3: SLC DEVICES 4: PROGRAMMING
5: GLOBALS 6: OUTPUTS/BACKPLANE
7: CONTROL MODULES SCROLL for more
1: DAY/NIGHT 2: PASSWORDS
3: AUTOLEARN 4: AUTOSETUP
5: ALM VERIFICATION 6: POSITIVE ALM SEQ
7: CLEAR EVENTS SCROLL for more
AUTO-LEARNING DEVICE ON SLC
AUTO-LEARNING DEVICE 025
AUTO-LEARNING DEVICES ON SLC
REGISTERED XXX DEVICES ON SLC
