Configuration and Programming
P/N 06-237041-001 3-15 February 2011
3-3.3 SET MENU FUNCTIONS
The Set functions allow the installer to change the sensitivity settings for SmartOne automatic
initiating devices, to address and register initiating and control devices, or to define global operating
parameters such as Global Acknowledgment of trouble and supervisory events. These commands are
also used to trigger automatic configuration routines such as AutoLearn and AutoSetup.
Figure 3-17 through Figure 3-30 outline the Set menu functions. Each function is explained in detail
in the remainder of Section 3-3.3.
Figure 3-17. FenwalNET 8000-ML Set Menu Functions (Fig. 1 of 14)
FOOTNOTES (Figure 3-17):
1 Time/Date. Set the Time. Purpose: To set the correct time for a FenwalNET 8000-ML control
unit. (Use either Steps 6a or 6b in table, depending on desired format).
2 Set Date. Set the Date. Purpose: To set the correct date for a FenwalNET 8000-ML control unit.
5 Port Control. Configure the Communications Ports. Purpose: To change the RS-232
communications ports for use with a serial printer, laptop or desktop computer (PC), and/or
terminal emulator.
3. SET
1. Time/Date
2. Port Control
1. Set Time
2. Set Date
1: AM 2: PM *
System Time (AM/PM 1-12 Hrs)
Enter the Time *_:__ (HH:MM)
Set Time (Mil 1-24 Hrs)
Enter the Time *_:__ (HH:MM)
Set Date
Enter the Date *_-__-__ (MM-DD-YY)
1. RS232 A
1: PRINTER 0: NOT USED *
1: PRINTER 0: NOT USED *
2. RS232 B
Cont’d
3. Time Format
1. AM/PM
2. Military
1: Enable 2. Disable
3. USB Printer
*=
Level-2 (Installer) Password required .
1
2
5
To Next Page
