UTC Fire and Security FenwalNET 8000-ML User Manual

Configuration and Programming
P/N 06-237041-001 3-37 February 2011
Figure 3-30. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 14 of 14)
FOOTNOTES (Figure 3-30):
39 LAM #01. Register Remote-Annunciator Modules. Purpose: To add/remove one or more
Remote LED Annunciator Modules.
3. SET
*
7. Control Modules
*= Level-2 (Installer) Password required .
6. LAM CONFIG 8. CALL FOR SERVICE7. CHANGE LAM ADDRESS
LAM CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
LAM CONFIGURATION
ENTER THE LAM NUMBER (01-15)*__

LAM #01
CURRENT VALUE
BUZZER:
ENABLE
PRESS ‘0’ TO CHANGE SETTING
LAM #01
USE SCROLL FOR OPTIONS, ENTER TO SELECT
BUZZER:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
LAM #01
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
After final parameter, the following appears:
LAM ADDRESS CHANGE
ENTER OLD ADDRESS (01-16)*__

LAM ADDRESS CHANGE
ENTER NEW ADDRESS (01-16)*__

CONFIRM CHANGE ADDRESS?
(1=Y, 2=N)__

EDIT MODE: CALL FOR SERVICE
CURRENT SOFT KEY ASSIGNMENT: ENABLED
(0: DISABLE, 1-4: ENABLE)
ENTER SOFT KEY ASSIGNMENT: __

EDIT MODE: CALL FOR SERVICE
Old first line:
FIRST LINE: ENTER UP TO 40 CHARACTERS
*******************************************************
EDIT MODE: CALL FOR SERVICE
Old second line:
SECOND LINE: ENTER UP TO 40 CHARACTERS
**********************************************************
EDIT MODE: CALL FOR SERVICE
Old third line:
THIRD LINE: ENTER UP TO 40 CHARACTERS
*******************************************************
EDIT MODE: CALL FOR SERVICE
Old fourth line:
FOURTH LINE: ENTER UP TO 40 CHARACTERS
**********************************************************
EDIT MODE: CALL FOR SERVICE
1: CONFIRM 2: CANCEL
39
