UTC Fire and Security FenwalNET 8000-ML User Manual

Parts List
P/N 06-237041-001 7-1 February 2011
CHAPTER 7
PARTS LIST
7-1 AVAILABLE PARTS
Refer to Table 7-1 below for descriptions and part numbers of available parts for the FenwalNET 8000-
ML
TM
control unit.
Category
Part
Number
Part Name
Systems and
Options:
FenwalNET
8000-ML
Systems
74-800100-001
FenwalNET 8000-ML 3-Tiered Control Unit (includes Main Control Board with
Keypad/Display, 5.4A Power Supply and Power Management Unit Board)
74-800200-001
FenwalNET 8000-ML 2-Tiered Control Unit (includes Main Control Board with
Keypad/Display, 5.4A Power Supply and Power Management Unit Board)
74-800101-002
FenwalNET 8000-ML 3-Tiered Control Unit, Canadian Application
(includes Main Control Board with Keypad/Display, 5.4A Power Supply,
Power Management Unit Board and Dead Front Cover -- with integrated LED
Annunciator Module)
74-800101-001
FenwalNET 8000-ML 3-Tiered Control Unit, Canadian Application
(includes Main Control Board with Keypad/Display, 5.4A Power Supply,
Power Management Unit Board and Dead Front Cover -- without integrated
LED Annunciator Module)
74-800201-002
FenwalNET 8000-ML 2-Tiered Control Unit, Canadian Application
(includes Main Control Board with Keypad/Display, 5.4A Power Supply,
Power Management Unit Board and Dead Front Cover -- with integrated LED
Annunciator Module)
74-800201-001
FenwalNET 8000-ML 2-Tiered Control Unit, Canadian Application
(includes Main Control Board with Keypad/Display, 5.4A Power Supply,
Power Management Unit Board and Dead Front Cover -- without integrated
LED Annunciator Module)
74-800102-001
City of Chicago FenwalNET 8000-ML Kit (consists of FenwalNET 8000-ML
3-Tiered Control Unit, City of Chicago Dead Front Cover, City of Chicago
Stand-Alone Control Box and mounting hardware)
74-800202-001
City of Chicago FenwalNET 8000-ML Kit (consists of FenwalNET 8000-ML
2-Tiered Control Unit, City of Chicago Dead Front Cover, City of Chicago
Stand-Alone Control Box and mounting hardware)
Expansion
Enclosures
74-800100-003
3-Tiered Expansion Enclosure (without window)
74-800200-003
2-Tiered Expansion Enclosure (without window)
Enclosure
Trim Rings
74-800100-004
Trim Ring for 3-Tiered Main and Expansion Enclosures
74-800200-004
Trim Ring for 2-Tiered Main and Expansion Enclosures
74-800300-004
Trim Ring for Remote Enclosure (for RDCM or R-LAM)
