Note: Selecting the isolation-macro option for a second time will execute a de-isolation routine for
all the devices and/or circuits that were isolated by the execution of the isolation macro. The
isolation macros toggle the devices in the command lists between the isolated and non-
isolated states.
6 De-Isolate Isolation Macro 1 or Isolation Macro 2. Purpose: To de-isolate the multiple input
and/or output isolations performed via Isolation Macro 1 or Isolation Macro 2.
3-3.2 LIST MENU FUNCTIONS
The List functions are used to view the set of isolated initiating devices and control unit-based and
SLC-based outputs. These functions are also used to display configuration settings for automatic
initiating devices, to display the list of devices on the SLC, and to view lower-level events that are not
displayed due to the occurrence of higher-level events.
Figure 3-13 through Figure 3-16 outline the List menu functions. Each function is explained in detail
in the remainder of Section 3-3.2.
Figure 3-13. FenwalNET 8000-ML List Menu Functions (Fig. 1 of 4)
2. LIST
Cont’d
1. Isolated Devices
1. SLC Devices
2. Event Logs
Enter Begin and End Dates for Range
Date Range *_-__-__ to __-__-__ (MMDDYY)

1. All System Events 
2. Range of Events 
3. SLC Test Results 
4. Walk Test Results 
SLC Module Selection
Enter SLC Module Number (1-8):_*
SLC Module Selection
Enter SLC Module Number (1-8):_*
3. Device Readings
SLC Module Selection
Enter SLC Module Number (1-8):_*
1
2
3
4
5
6
2. Outputs
3. Control Modules
4. BACKPLANE
Enter Module Logical Address:_*
Isolate Control Modules 
SLC Test Results Listing
SLC Devices*__ to ___ (1-255)
Walk Test Results Listing
SLC Devices*__ to ___ (1-255)
SLC Device Readings
SLC Devices*__ to ___ (1-255)
