FOOTNOTES (Figure 3-11):
3 Control Modules. Purpose: To prevent selected LAM and RDCM modules from displaying
messages, or from carrying out activation instructions issued by the FenwalNET 8000-ML control
unit.
Figure 3-12. FenwalNET 8000-ML Isolate Menu Functions (Cont’d - Fig. 3 of 3)
FOOTNOTES (Figure 3-12):
4 Globally Isolate Initiating Devices. Purpose: To enable previously-isolated remote-annunciator
modules to display messages or to execute activation instructions issued by the FenwalNET 8000-
ML Control Unit.
5 Execute a User-Defined Inputs/Outputs Isolation Routine. Purpose: To perform multiple
input and/or output isolations via a single menu selection. The inputs and/or outputs to be
isolated are assigned to an "isolation macro" that is defined via the FenwalNET 8000-ML
Configuration Software. The FenwalNET 8000-ML Configuration Software permits two "isolation
macros" to be defined. Each macro can process up to ten separate isolation commands. The
specific isolation commands are executed when either the "Isolation Macro 1" or "Isolation Macro
2" menu options are selected. The isolation lists can include any of the following: initiating
devices, control modules, or control-unit-based outputs individually or by address range. This
includes automatic initiating devices, monitor modules, control modules, releasing circuits,
notification-appliance circuits, combination notification-appliance/releasing circuits, and
programmable relays. Refer to the FenwalNET 8000-ML Configuration Software User’s Guide,
P/N 06-237042-001, for the procedure to assign initiating devices, control modules, or control-
unit-based outputs to either "Isolation Macro 1" or "Isolation Macro 2".
1. ISOLATE
1. Inputs * 
Global Isolation of Inputs
1. Isolate 2. De-Isolate *

4. Global Isolate
2. Outputs * 
Global Isolation of Outputs
1. Isolate 2. De-Isolate *

5. MACROS
1. MACRO 1
2. MACRO 2
3. MACRO 3
4. MACRO 4
Isolation Macro 1
1: Isolate 2: De-Isolate *

Isolation Macro 1
1: Isolate 2: De-Isolate *

Isolation Macro 1
1: Isolate 2: De-Isolate *

Isolation Macro 1
1: Isolate 2: De-Isolate *

45, 6
