FOOTNOTES (Figure 3-10):
1 SLC Devices. Purpose: To prevent initiating and trouble signals from selected SmartOne
automatic detectors and monitor modules from being processed and acted upon by the
FenwalNET 8000-ML control unit. Also to prevent selected SmartOne control and relay modules
from carrying out activation instructions issued by the FenwalNET 8000-ML control unit. Note:
An SLC device can only be isolated if it is not in either a trouble or alarm condition.
2 RRM Groups. Outputs. Purpose: To prevent selected control-unit-based outputs from carrying
out activation instructions issued by the FenwalNET 8000-ML control unit.
Figure 3-11. FenwalNET 8000-ML Isolate Menu Functions (Cont’d - Fig. 2 of 3)
1. ISOLATE
Cont’d
3. Control Modules
1. Isolate LAM
Enter the LAM Number (01-16) *
Enter the LAM Number (01-16) *
2. Deisolate LAM
3
Enter the RDCM Number (01-15) *
3. Isolate RDCM
Enter the RDCM Number (01-15) *
4. Deisolate RDCM
To Next Page
