Figure 3-10. FenwalNET 8000-ML Isolate Menu Functions (Fig. 1 of 3)
1. ISOLATE
2. Outputs
1. NACs
1: Isolate 2. De-Isolate *
Cont’d
Press “0” KeyEnter Password
2. RNAC Circuits
RNAC * to RNAC
1: Isolate 2. De-Isolate *
3. Relays
Relay * to Relay
1: Isolate 2. De-Isolate *
4. BACKPLANE
1. SLC Devices
1. SLC Inputs *
Isolate SLC Devices
Devices from *__ to ___
1: Isolate 2: De-Isolate *
2. SLC Outputs *
Isolate SLC Devices
Devices from *__ to ___
1: Isolate 2: De-Isolate *
SLC Device Isolation
Enter Module Logical Address (1-8)__ *
Isolation RNAC
1: Isolate 2. De-Isolate *
1: RNAC
Enter Logical Address Range __ to __ *
Isolation RELAY
1: Isolate 2. De-Isolate *
2: RELAY
Enter Logical Address Range __ to __ *
Isolation CITY TIE
1: Isolate 2. De-Isolate *
3: CITY TIE
Isolation PMU
1: Isolate 2. De-Isolate *
4: PMU
Enter Logical Address Range __ to __ *
1. SLC Devices
2. RRM Groups
RRM Group Isolation
Enter RRM Module Number (1-7)__ *
1: Isolate 2: De-Isolate *
1
2
2
To Next Page
