Figure 3-29. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 13 of 14)
3. SET
*
7. Control Modules
*= Level-2 (Installer) Password required .
1. REGISTER
REGISTRATION MODE
1. ENTER THE LAM
NUMBER (01-16):_
REGISTER CONTROL / DISPLAY
MODULE
1: LAM 2: RDCM *

DE-REGISTER CONTROL / DISPLAY
MODULE
1: LAM 2: RDCM *

2. DE-REGISTER
REGISTRATION MODE
2. ENTER THE RDCM
NUMBER (0-15):_
DEREGISTRATION MODE
1. ENTER THE LAM NUMBER
(01-16):_
DEREGISTRATION MODE
2. ENTER THE
RDCM NUMBER (01-15):_
1. ALL
3. RESET
2. MAIN DISPLAY
3. LAM
4. RDCM
RESET MODE
ENTER THE LAM NUMBER (01-16):__
RESET MODE
ENTER THE RDCM NUMBER (01-15):__
After final parameter, the following appears:
4. RDCM CONFIG
RDCM CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
RDCM CONFIGURATION
2. ENTER THE RDCM NUMBER (01-15)*__

RDCM #01
CURRENT VALUE
MASTER:
ENABLE
PRESS ‘0’ TO CHANGE SETTING
RDCM #01
USE SCROLL FOR OPTIONS, ENTER TO SELECT
MASTER:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
RDCM #01
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
5. CHANGE RDCM ADDR
RDCM ADDRESS CHANGE
ENTER OLD ADDRESS (01-15)*__

RDCM ADDRESS CHANGE
ENTER NEW ADDRESS (01-15)*__

CONFIRM CHANGE ADDRESS?
(1=Y, 2=N)__

