vacon • 103
Local contacts: http://drives.danfos
s.com/danfoss-drives/
local-contacts/
8
8.3.4
Fuses
The recommended fuse types for the heater su
pply
voltage are shown in the table below.
8.3.5
Mounting in
structions: MM4 Example
Figure 77. Heater option for
MM4.
Table 39
. Fuse
s ratings.
F
uses for heat
er suppl
y voltage input - 230V
AC
gG/gL (IEC 60269-1)
500V
class T ( UL& CSA)
300V
class J ( UL& C
SA)
300V
1A
1A
1A
104
106
