Vacon 100 X Installation, Technical And Maintenance Manual

7
vacon • 64 Technical data
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
7.1.2 Mains voltage 3AC 380-480/500V
NOTE: The rated currents in given ambient temperatures (in Table 29 and Table 30) are achieved
only when the switching frequency is equal to or less than the factory default.
Table 29. Power ratings of VACON
®
100 X, supply voltage 3AC 380-480/500V, high overload.
Mains voltage 3AC 380-480/500V, 50/60 Hz
AC drive
type
Input
current
[A]
Loadability
Motor shaft power
400V 480V
Rated continuous
current I
N
[A]
50% overload
current
[A]
Max current
I
S
[kW] [HP]
MM4
0003 3.4 3.4 5.1 6.8 1.1 1.5
0004 4.6 4.8 7.2 9.6 1.5 2.0
0005 5.4 5.6 8.4 11.2 2.2 3.0
0008 8.1 8.0 12.0 16.0 3.0 5.0
0009 9.3 9.6 14.4 19.2 4.0 5.0
0012 11.3 12.0 18.0 24.0 5.5 7.5
MM5
0016 15.4 16.0 24.0 32.0 7.5 10.0
0023 21.3 23.0 34.5 46.0 11.0 15.0
0031 28.4 31.0 46.5 62.0 15.0 20.0
MM6
0038 36.7 38.0 57.0 76.0 18.5 25.0
0046 43.6 46.0 69.0 92.0 22.0 30.0
0061 58,2 61.0 91.5 122.0 30.0 40.0
Table 30. Power ratings of VACON
®
100 X, supply voltage 3AC 380-480/500V, low overload.
Mains voltage 3AC 380-480/500V, 50/60 Hz
AC drive
type
Input
current
[A]
Loadability
Motor shaft power
400V 480V
Rated continuous
current I
N
[A]
10% overload
current
[A]
Max current
I
S
[kW] [HP]
MM6
0072 67.5 72.0 80.0 108.0 37.0 50.0
