Vacon 100 X Installation, Technical And Maintenance Manual

Solar pump application vacon • 123
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
10
10. SOLAR PUMP APPLICATION
The installation instructions in this chapter are intended only for VACON
®
100 X Drives with addi-
tional solar pump application.
10.1 Danger
10.2 Warning
10.3 DC Fuse selection
The fuses on the DC-Input of the inverter must have the following characteristics:
It is recommended to use gPV fuses, which are developed for solar application, in order to protect
cables and panels against reverse overcurrent, when multiple strings are connected in parallel.
See chapter 10.4. for recommended gPV fuse manufacturer.
The photovoltaic fuses have to meet the IEC 60269-6 or the UL 2579 standard.
The terminals are live when the VACON
®
100 X Drive is connected to a photovoltaic system.
Photovoltaic cells generate DC voltage even at low intensity of sunlight.
Wait 30 seconds until the drive is discharged, before switching between AC and DC supply
(photovoltaic system) and vice versa.
Do not remove the EMC screws in the solar pump application. IT (impedance-grounded) AC
supply network is not allowed in the solar pump application.
Table 51. Fuse characteristics
Fuse type Min. Voltage rating
DC current 1000 V
