3
vacon • 24 Mounting
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
3.4 Introduction of modules
The mechanical concept of VACON
®
100 X drive is based on two segregated parts, power and con-
trol, connected to each other by pluggable terminals. The power unit, called powerhead, includes
all the power electronics such as the EMC-filter, IGBTs, capacitors, choke or power boards while
the control board and the control terminals are located in the terminal box.
Figure 14. VACON
®
100 X drive modules.
Powerhead
Terminal box
