vacon • 18 Receipt of delivery
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
2.3 Unpacking and lifting the AC drive
The weights of the AC drives vary according to enclosure size. You may need to use a piece of special
lifting equipment to move the drive from its package. Note the weights of each individual enclosure
size in Table below.
VACON
®
100 X drives have undergone scrupulous tests and quality checks at the factory before they
are delivered to the customer. However, after unpacking the product, check that no signs of trans-
port damage are to be found on the product and that the delivery is complete.
Should the drive have been damaged during shipping, please contact the cargo insurance company
or the carrier in the first instance.
2.4 Accessories
After having opened the transport package and lifted the drive out, check immediately that these
various accessories were included in the delivery. The contents of the accessories bag differ by
drive size:
2.4.1 Frame MM4
Table 4. Frame weights.
Enclosure
size
Weight
[kg] [lb]
MM4 8.8 19.4
MM5 14.9 32.8
MM6 31.5 69.4
Table 5. Content of accessory bag, MM4.
Item Quantity Purpose
STO terminal connector 1
Six pin black connector (see
Figure 9) to use STO function
M4 x 12 DIN6900-3-Combi-Delta-Tx
screw
10 Screws for control cable clamps
M1-3 Cable clamp 5 Clamping control cables
M4 x 12 DIN6900-3-Combi-Delta-Tx
screw
6 Screws for power cable clamps
M25 Cable clamp 3 Clamping power cables
‘Product modified’ sticker 1 Information about modifications
HMI cap
*
*. Provided only if the drive is delivered with the keypad.
1 Closing cap for the HMI connector
