8.4 Option boards
VACON
®
100 X drive family embodies a wide selection of expander boards with which the available
I/O of VACON
®
100 X AC drive can be increased and its versatility improved.
There are two board slots (labelled D and E) on the VACON
®
100 X control board. To locate the slot,
see chapter 5. Usually, when the AC drive is delivered from the factory, the control unit does not
include any option board in the board slots.
The following option boards are supported:
See the Option boards User’s Manual to use and install the option boards.
Table 40. Option boards supported in VACON
®
100 X.
Code Description Note
OPTB1
Option board with six bidirec-
tional terminals.
With jumper blocks it is possible to
use each terminal as digital input or
as digital output.
OPTB2
I/O expander board with a
thermistor input and two relay
outputs.
OPTB4
I/O expander board with one
galvanically isolated analogue
input and two
galvanically isolated analogue
outputs (standard signals
0(4)…20mA).
OPTB5
I/O expander board with three
relay outputs
OPTB9
I/O expander board with five
42…240 VAC digital inputs and
one relay output.
OPTBF
I/O expander board with ana-
logue output, digital output and
relay output.
On the OPTBF board, there is one
jumper block for selecting the ana-
logue output mode (mA/V).
OPTBH
Temperature measurement
board with three individual
channels.
Supported sensors: PT100, PT1000,
NI1000, KTY84-130, KTY84-150,
KTY84-131
OPTBK AS-interface option board
OPTC4 Lonworks option board
Pluggable connector with screw ter-
minals
OPTE3 Profibus DP option board
Pluggable connector with screw ter-
minals
OPTE5 Profibus DP option board 9-pin Sub-D terminal
OPTE6 CANopen option board
OPTE7 DeviceNet option board
