Receipt of delivery vacon • 17
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
2
2.2 order codes
The order codes for VACON
®
100 X drive family are shown in the following table:
Table 3. Order codes of VACON
®
100 X. See chapter 7 for more details.
Enclosure size Order code Description
Supply voltage 3AC 208-240V
MM4
VACON0100-3L-0007-2-X 1.1 kW - 1.5 HP drive
VACON0100-3L-0008-2-X 1.5 kW - 2.0 HP drive
VACON0100-3L-0011-2-X 2.2 kW - 3.0 HP drive
VACON0100-3L-0012-2-X 3.0 kW - 4.0 HP drive
MM5
VACON0100-3L-0018-2-X 4.0 kW - 5.0 HP drive
VACON0100-3L-0024-2-X 5.5 kW - 7.5 HP drive
VACON0100-3L-0031-2-X 7.5 kW - 10.0 HP drive
MM6
VACON0100-3L-0048-2-X 11.0 kW - 15.0 HP drive
VACON0100-3L-0062-2-X 15.0 kW - 20.0 HP drive
Supply voltage 3AC 380-480V
MM4
VACON0100-3L-0003-4-X 1.1 kW - 1.5 HP drive
VACON0100-3L-0004-4-X 1.5 kW - 2.0 HP drive
VACON0100-3L-0005-4-X 2.2 kW - 3.0 HP drive
VACON0100-3L-0008-4-X 3.0 kW - 4.0 HP drive
VACON0100-3L-0009-4-X 4.0 kW - 5.0 HP drive
VACON0100-3L-0012-4-X 5.5 kW - 7.5 HP drive
MM5
VACON0100-3L-0016-4-X 7.5 kW - 10.0 HP drive
VACON0100-3L-0023-4-X 11.0 kW - 15.0 HP drive
VACON0100-3L-0031-4-X 15.0 kW - 20.0 HP drive
MM6
VACON0100-3L-0038-4-X 18.5 kW - 25.0 HP drive
VACON0100-3L-0046-4-X 22.0 kW - 30.0 HP drive
VACON0100-3L-0061-4-X 30.0 kW - 40.0 HP drive
VACON0100-3L-0072-4-X 37.0 kW - 50.0 HP drive
Supply voltage 3AC 380-500V
MM4
VACON0100-3L-0003-5-X 1.1 kW - 1.5 HP drive
VACON0100-3L-0004-5-X 1.5 kW - 2.0 HP drive
VACON0100-3L-0005-5-X 2.2 kW - 3.0 HP drive
VACON0100-3L-0008-5-X 3.0 kW - 4.0 HP drive
VACON0100-3L-0009-5-X 4.0 kW - 5.0 HP drive
VACON0100-3L-0012-5-X 5.5 kW - 7.5 HP drive
MM5
VACON0100-3L-0016-5-X 7.5 kW - 10.0 HP drive
VACON0100-3L-0023-5-X 11.0 kW - 15.0 HP drive
VACON0100-3L-0031-5-X 15.0 kW - 20.0 HP drive
MM6
VACON0100-3L-0038-5-X 18.5 kW - 25.0 HP drive
VACON0100-3L-0046-5-X 22.0 kW - 30.0 HP drive
VACON0100-3L-0061-5-X 30.0 kW - 40.0 HP drive
VACON0100-3L-0072-5-X 37.0 kW - 50.0 HP drive
