Vacon NX User Manual

Control keypad vacon • 129
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
7
Functions in the System menu
Table 53. System menu functions
Code Function Min Max Unit Default Cust Selections
S6.1 Language selection English
Available selections
depend on the language
package.
S6.2 Application selection
Basic
Applica-
tion
Basic Application
Standard Application
Local/Remote control Appl.
Multi-Step Application
PID Control Application
Multi-Purpose Control
Appl.
Pump and Fan Control
Appl.
S6.3 Copy parameters
S6.3.1 Parameter sets
Store set 1
Load set 1
Store set 2
Load set 2
Load factory defaults
S6.3.2 Load up to keypad All parameters
S6.3.3 Load down from keypad
All parameters
All but motor parameters
Application parameters
P6.3.4 Parameter backup Yes
Yes
No
S6.4 Compare parameters
S6.4.1 Set1 Not used
S6.4.2 Set2 Not used
S6.4.3 Factory settings
S6.4.4 Keypad set
S6.5 Security
S6.5.1 Password Not used 0 = Not used
P6.5.2 Parameter lock
Change
Enabled
Change Enabled
Change Disabled
S6.5.3 Start-up wizard
No
Yes
S6.5.4 Multimonitoring items
Change Enabled
Change Disabled
S6.6 Keypad settings
P6.6.1 Default page
P6.6.2
Default page/
Operating menu
P6.6.3 Timeout time 0 65535 s 30
P6.6.4 Contrast 0 31 18
P6.6.5 Backlight time Always 65535 min 10
S6.7 Hardware settings
P6.7.3 HMI acknowledg. timeout 200 5000
P6.7.4 HMI number of retries 1 10
S6.8 System information

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
