Vacon NX User Manual

Appendices vacon • 235
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
13
1
SHT fuses can be assembled into DIN fuse base of the corresponding size
Table 116. Fuse sizes (Bussman aR) for VACON
®
NX AFE units (525—690 V)
Chassis
Type I
th
[A]
DIN43620 DIN43653 (110mm)
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses /
phase 3~
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse size
1
CH61 0170 170 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH61 0208 208 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH61 0261 261 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH62 0325 325 170M6305 3SHT 170M8636 3TN/110 1250 700 1
CH62 0385 385 170M6305 3SHT 170M8636 3TN/110 1250 700 1
CH62 0416 416 170M6305 3SHT 170M8636 3TN/110 1250 700 1
CH62 0460 460 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH62 0502 502 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH63 0590 590 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH63 0650 650 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH63 0750 750 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH64 0820 820 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH64 0920 920 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 1030 1030 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 1180 1180 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 1300 1300 170M6305 3SHT 170M8636 3TN/110 1250 700 3
CH64 1500 1500 170M6277 3SHT 170M8639 3TN/110 1100 1000 3

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
