vacon • 234 Appendices
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
____________________________
1
SHT fuses can be assembled into DIN fuse base of the corresponding size
CH62 0460 460 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH62 0520 520 170M6277 3SHT
170M8639 3TN/110 1100 1000 1
CH62 0590 590 170M6277 3SHT
170M8639 3TN/110 1100 1000 1
CH62 0650 650 170M6305 3SHT
170M8636 3TN/110 1250 700 2
CH62 0730 730 170M6305 3SHT
170M8636 3TN/110 1250 700 2
CH63 0820 820 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH63 0920 920 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH63 1030 1030 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH63 1150 1150 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 1370 1370 170M6277 3SHT
170M8639 3TN/110 1100 1000 3
CH64 1640 1640 170M6277 3SHT
170M8639 3TN/110 1100 1000 3
CH64 2060 2060 170M6277 3SHT
170M8639 3TN/110 1100 1000 4
CH64 2300 2300 170M6277 3SHT
170M8639 3TN/110 1100 1000 4
Table 115. Fuse sizes (Bussman aR) for VACON
®
NX AFE units (380—500 V)
Chassis Type
I
th
[A]
DIN43620
DIN43653
(80mm)
DIN43653
(110mm)
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses /
phase 3~
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse
size
1
