Appendices vacon • 233
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
13
1
SHT fuses can be assembled into DIN fuse base of the corresponding size
Fuse sizes (Bussman aR) for VACON
®
NX Liquid-Cooled (640—1100 V) inverters
Chassis Type
I
th
[A]
DIN43620 DIN43653 (110mm)
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of fuses/
pole
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse size
CH61 0170 170 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH61 0208 208 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH61 0261 261 170M6202 3SHT 170M8633 3TN/110 1250 500 1
CH62 0325 325 170M6305 3SHT 170M8636 3TN/110 1250 700 1
CH62 0385 385 170M6305 3SHT 170M8636 3TN/110 1250 700 1
CH62 0416 416 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH62 0460 460 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH62 0502 502 170M6277 3SHT 170M8639 3TN/110 1100 1000 1
CH63 0590 590 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH63 0650 650 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH63 0750 750 170M6305 3SHT 170M8636 3TN/110 1250 700 2
CH64 0820 820 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 0920 920 170M6277 3SHT 170M8639 3TN/110 1100 1000 2
CH64 1030 1030 170M6277 3SHT 170M8639 3TN/110 1100 1000 3
CH64 1180 1180 170M6277 3SHT 170M8639 3TN/110 1100 1000 3
CH64 1300 1300 170M6277 3SHT 170M8639 3TN/110 1100 1000 3
CH64 1500 1500 170M6277 3SHT 170M8639 3TN/110 1100 1000 3
CH64 1700 1700 170M6277 3SHT 170M8639 3TN/110 1100 1000 3
Table 115. Fuse sizes (Bussman aR) for VACON
®
NX AFE units (380—500 V)
Chassis Type
I
th
[A]
DIN43620
DIN43653
(80mm)
DIN43653
(110mm)
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses /
phase 3~
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse
size
1
aR fuse
part nr.
Fuse
size
1
CH3 0016 16 170M2679 DIN00 170M4828 00TN/80 1000 63 1
CH3 0022 22 170M2679 DIN00 170M4828 00TN/80
1000 63 1
CH3 0031 31 170M2679 DIN00 170M4828 00TN/80
1000 63 1
CH3 0038 38 170M2679 DIN00 170M4828 00TN/80
1000 63 1
CH3 0045 45 170M2683 DIN00 170M4832 00TN/80
1000 160 1
CH3 0061 61 170M2683 DIN00 170M4832 00TN/80
1000 160 1
CH4 0072 72 170M2683 DIN00 170M4832 00TN/80 1000 160 1
CH4 0087 87 170M2683 DIN00 170M4832 00TN/80 1000 16 1
CH4 0105 105 170M2683 DIN00 170M4832 00TN/80 1000 160 1
CH4 0140 140 170M4199 1SHT 170M4985 1TN/110 1250 400 1
CH5 0168 168 170M4199 1SHT
170M4985 1TN/110 1250 400 1
CH5 0205 205 170M4199 1SHT
170M4985 1TN/110 1250 400 1
CH5 0261 261 170M4199 1SHT
170M4985 1TN/110 1250 400 1
CH61 0300 300 170M6202 3SHT 170M8633 3TN/110 1250 500 1
CH61 0385 385 170M6305 3SHT 170M8636 3TN/110 1250 700 1
