Vacon NX User Manual

13
vacon • 232 Appendices
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
______________________________________
1
Tj = 25 °C
2
SHT fuses can be assembled into DIN fuse base of the corresponding size
Table 114. Fuse sizes (Bussman aR) for VACON
®
NX Liquid-Cooled (450—800 V) inverters
Chassis Type
I
th
[A]
DIN43620
DIN43653
(80mm)
DIN43653
(110mm)
Fuse
U
n
[V]
Fuse
I
n
[A]
Qty. of
fuses/
pole
aR fuse
part nr.
Fuse
size
aR fuse
part nr
Fuse
size
aR fuse
part nr.
Fuse
size
CH3 0016 16 170M3810
DIN1
1
170M3060 1*TN/80 170M3210 1*TN/110 690 63 1
CH3 0022 22 170M3810
DIN1
1
170M3060 1*TN/80 170M3210 1*TN/110 690 63 1
CH3 0031 31 170M3810
DIN1
1
170M3060 1*TN/80 170M3210 1*TN/110 690 63 1
CH3 0038 38 170M3813
DIN1
1
170M3063 1*TN/80 170M3213 1*TN/110 690 125 1
CH3 0045 45 170M3813
DIN1
1
170M3063 1*TN/80 170M3213 1*TN/110 690 125 1
CH3 0061 61 170M3813
DIN1
1
170M3063 1*TN/80 170M3213 1*TN/110 690 125 1
CH4 0072 72 170M3815
DIN1
1
170M3063 1*TN/80 170M3213 1*TN/110 690 200 1
CH4 0087 87 170M3815
DIN1
1
170M3065 1*TN/80 170M3215 1*TN/110 690 200 1
CH4 0105 105 170M3815
DIN1
1
170M3065 1*TN/80 170M3215 1*TN/110 690 200 1
CH4 0140 140 170M3819
DIN1
1
170M3069 1*TN/80 170M3219 1*TN/110 690 400 1
CH5 0168 168 170M3819
DIN1
1
170M3069 1*TN/80 170M3219 1*TN/110 690 400 1
CH5 0205 205 170M3819
DIN1
1
170M3069 1*TN/80 170M3219 1*TN/110 690 400 1
CH5 0261 261 170M6808 DIN3 170M6058 3TN/80 170M6208 3TN/110 690 500 1
CH61 0300 300 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 1
CH61 0385 385 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 1
CH62 0460 460 170M6814 DIN3 170M6064 3TN/80 170M6214 3TN/110 690 1000 1
CH62 0520 520 170M6814 DIN3 170M6064 3TN/80 170M6214 3TN/110 690 1000 1
CH62 0590 590 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 2
CH62 0650 650 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 2
CH62 0730 730 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 2
CH63 0820 820 170M6814 DIN3 170M6064 3TN/80 170M6214 3TN/110 690 1000 2
CH63 0920 920 170M6814 DIN3 170M6064 3TN/80 170M6214 3TN/110 690 1000 2
CH63 1030 1030 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 3
CH63 1150 1150 170M6812 DIN3 170M6062 3TN/80 170M6212 3TN/110 690 800 3
CH64 1370 1370 170M8547
3SHT
2
170M6066 3TN/80 170M6216 3TN/110 690 1250 3
CH64 1640 1640 170M8547
3SHT
2
170M6066 3TN/80 170M6216 3TN/110 690 1250 3
CH64 2060 2060 170M8550
3SHT
2
170M6069 3TN/80 170M6219 3TN/110 690 1600 3
CH64 2300 2300 170M8550
3SHT
2
170M6069 3TN/80 170M6219 3TN/110 690 1600 3

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
