Technical data vacon • 25
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
4
4.2.1.2 VACON
®
NX Liquid-Cooled AC drive – Mains voltage 525—690 VAC
Table 8. Power ratings of VACON
®
NX Liquid-Cooled AC drive (6-pulse),
supply voltage 525—690 VAC
Mains voltage 525-690 VAC, 50/60 Hz, 3~, 6-pulse drives
AC drive type
Drive output
Power loss
c/a/T
*)
[kW]
Chassis
Current Motor output power
Thermal
I
th
[A]
Rated contin.
I
L
[A]
Rated contin.
I
H
[A]
Optimum
motor at I
th
(525V) [kW]
Optimum
motor at I
th
(690V) [kW]
0170_6 170 155 113 110 160 4.0/0.2/4.2 CH61
0208_6 208 189 139 132 200 4.8/0.3/5.1 CH61
0261_6 261 237 174 160 250 6.3/0.3/6.6 CH61
0325_6 325 295 217 200 300 7.2/0.4/7.6 CH72
0385_6 385 350 257 250 355 8.5/0.5/9.0 CH72
0416_6 416 378 277 250 355 9.1/0.5/9.6 CH72
0460_6 460 418 307 300 400 10.0/0.5/10.5 CH72
0502_6 502 456 335 355 450 11.2/0.6/11.8 CH72
0590_6 590 536 393 400 560 12.4/0.7/13.1 CH63
0650_6 650 591 433 450 600 14.2/0.8/15.0 CH63
0750_6 750 682 500 500 700 16.4/0.9/17.3 CH63
0820_6 820 745 547 560 800 17.3/1.0/18.3 CH74
0920_6 920 836 613 650 850 19.4/1.1/20.5 CH74
1030_6 1030 936 687 700 1000 21.6/1.2/22.8 CH74
1180_6 1180 1073 787 800 1100 25.0/1.3/26.3 CH74
1300_6 1300 1182 867 900 1200 27.3/1.5/28.8 CH74
1500_6 1500 1364 1000 1050 1400 32.1/1.7/33.8 CH74
1700_6 1700 1545 1133 1150 1550 36.5/1.9/38.4 CH74
1850_6 1850 1682 1233 1250 1650 39.0/2.0/41.0 2*CH74
2120_6 2120 1927 1413 1450 1900 44.9/2.4/47.3 2*CH74
2340_6 2340 2127 1560 1600 2100 49.2/2.6/51.8 2*CH74
2700_6 2700 2455 1800 1850 2450 57.7/3.1/60.8 2*CH74
3100_6 3100 2818 2066 2150 2800 65.7/3.4/69.1 2*CH74
Table 9. Power ratings of VACON
®
NX Liquid-Cooled AC drive (12-pulse),
supply voltage 525—690 VAC
Mains voltage 525-690 VAC, 50/60 Hz, 3~, 12-pulse drives
AC drive type
Drive output
Power loss
c/a/T
*)
[kW]
Chassis
Current Motor output power
Thermal
I
th
[A]
Rated contin.
I
L
[A]
Rated contin.
I
H
[A]
Optimum
motor at I
th
(525V) [kW]
Optimum
motor at I
th
(690V) [kW]
0325_6 325 295 217 200 250 7.2/0.4/7.6 CH72
0385_6 385 350 257 250 355 8.5/0.5/9.0 CH72
