Vacon NX User Manual

Electrical cabling and connections vacon • 79
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6
1)
Due to insufficient number of terminal bolt connections for required amount of cables, the cabinet must be
equipped with an external flexible cable connection block at both mains and motor ends if stiff cable type is
used.
Data in Italic refer to drives with 12-pulse supply.
Units with 6-pulse supply
Note that all other sizes have 3 input terminals except for size CH74, which has 9 input terminals.
CH74 cables must be connected symmetrically between 3 parallel connected rectifiers in each
phase.
Units with 12-pulse supply
12-pulse supply can be used with drives of sizes CH72 and CH74. The number of input terminals for
both is 6.
If 12-pulse supply is used, pay also attention to the fuse selection, see page 82 and page 83.
See the tightening torques of bolts in Table 40.
CH74
1)
2060_5 2060 8*(3*185+95) 300 Cu/Al *** 4/M12
CH74
1)
2300_5 2300 9*(3*185+95) 300 Cu/Al *** 6/M12
Table 39. Mains cable sizes, 525—690 V
Chassis Type I
th
Mains cable
Cu [mm
2
]
Terminal cable size
Max. number
of cables/
Bolt size
Main terminal
[mm
2
], max.
Earth terminal
[mm
2
]
CH61 0170_6 170 3*95+50 185 Cu/Al 25—95 2/M12
CH61 0208_6 208 3*150+70 185 Cu/Al 25—95 2/M12
CH61 0261_6 261 3*185+95 185 Cu/Al 2 25—95 2/M12
CH72/CH72 0325_6 325 2*(3*95+50) 300 Cu/Al 25—185 2 (or 4)/M12
CH72/CH72 0385_6 385 2*(3*120+70) 300 Cu/Al 25—185 2 (or 4)/M12
CH72/CH72 0416_6 416 2*(3*150+70) 300 Cu/Al 25—185 2 (or 4)/M12
CH72/CH72 0460_6 460 2*(3*185+95) 300 Cu/Al 25—185 2 (or 4)/M12
CH72/CH72 0502_6 502 2*(3*185+95) 300 Cu/Al 25—185 2 (or 4)/M12
CH63
0590_6
0650_6
590
650
2*(3*240+120) 300 Cu/Al **** 2/M12
CH63
1)
0750_6 750 3*(3*185+95) 300 Cu/Al **** 2/M12
CH74 0820_6 820 3*(3*185+95) 300 Cu/Al *** 6/M12
CH74 0820_6 820 4*(3*150+70) 300 Cu/Al *** 4/M12
CH74 0920_6 920 3*(3*240+120) 300 Cu/Al *** 6/M12
CH74 0920_6 920 4*(3*185+95) 300 Cu/Al *** 4/M12
CH74 1030_6 1030 6*(3*95+50) 300 Cu/Al *** 6/M12
Table 38. Mains cable sizes for AC drives, 400—500 V
Chassis Type I
th
Mains cable
Cu [mm
2
]
Terminal cable size
Max. number
of cables/
Bolt size
Main terminal
[mm
2
], max
Earth terminal
[mm
2
]
