Electrical cabling and connections vacon • 85
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
6
6.1.3.2 Fuse sizes, inverters
Each DC supply line must be equipped with an aR fuse according to the tables below.
Table 43. Fuse sizes for VACON
®
NX Liquid-Cooled (450—800 V) inverters
Chas
sis
Type
I
th
[A]
DIN43620
"TTF" threaded end
"7X"
or size 83 with end
contacts
"TTQF" threaded
end size84 or
"PLAF" 2x84
with end
contacts
Fuse
I
n
[A]
Fuse
size
aR fuse
part nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
CH3 0016 16 DIN0 PC70UD13C50PA 2 PC70UD13C50TF 2 - - 50
CH3 0022 22 DIN0 PC70UD13C50PA 2 PC70UD13C50TF 2 - - 50
CH3 0031 31 DIN0 PC70UD13C80PA 2 PC70UD13C63TF 2 - - 80/63
CH3 0038 38 DIN0 PC70UD13C80PA 2 PC70UD13C80TF 2 - - 125
CH3 0045 45 DIN0 PC70UD13C125PA 2 PC70UD13C125TF 2 - - 125
CH3 0061 61 DIN0 PC70UD13C125PA 2 PC70UD13C125TF 2 - - 125
CH4 72 72 DIN0 PC70UD13C200PA 2 PC70UD13C200TF 2 - - 200
CH4 0087 87 DIN0 PC70UD13C200PA 2 PC70UD13C200TF 2 - - 200
CH4 0105 105 DIN0 PC70UD13C200PA 2 PC70UD13C200TF 2 - - 200
CH4 0140 140 DIN1 PC71UD13C315PA 2 PC71UD13C315TF 2 - - 315
CH5 0168 168 DIN1 PC71UD13C315PA 2 PC71UD13C315TF 2 - - 315
CH5 0205 205 DIN1 PC71UD13C400PA 2 PC71UD13C400TF 2 - - 400
CH5 0261 261 DIN3 PC73UD13C500PA 2 PC73UD13C500TF 2 - - 500
CH61 0300 300 DIN3 PC73UD13C630PA 2 PC73UD13C630TF 2 - - 630
CH61 0385 385 DIN3 PC73UD11C800PA 2 PC73UD13C800TF 2 - - 800
CH62 460 460 DIN3 PC73UD90V11CPA 2 PC73UD95V11CTF 2 - - 1100
CH62 520 520 DIN3 PC73UD90V11CPA 2 PC73UD95V11CTF 2 - - 1100
CH62 590 590 DIN3 PC73UD13C630PA 4 PC73UD95V11CTF 2 - -
630/
1100
CH62 650 650 DIN3 PC73UD13C630PA 4 PC83UD11C13CTF 2 - -
630/
1300
CH62 730 730 DIN3 PC73UD11C800PA 4 PC83UD11C13CTF 2 - -
800/
1300
CH63 0820 820 DIN3 PC73UD11C800PA 4 PC73UD13C800TF 4
PC84UD13
C15CTQ
2
800/
1500
CH63 0920 920 DIN3 PC73UD90V11CPA 4 PC73UD95V11CTF 4
PC84UD12
C18CTQ
2
1100/
1800
CH63 1030 1030 DIN3 PC73UD90V11CPA 4 PC73UD13C800TF 4
PC84UD11
C20CTQ
2
1100/
800/
2000
CH63 1150 1150 - - - PC83UD11C13CTF 4
PC84UD11
C22CTQ
2
1300/
2200
CH64 1370 1370 - - - PC83UD11C14CTF 4
PC84UD10
C27CTQ
2
1400/
2700
