vacon • 86 Electrical cabling and connections
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
CH64 1640 1640 - - - PC73UD13C800TF 8
PC87UD12
C30CP50
2
800/
3000
CH64 2060 2060 - - - PC73UD95V11CTF 8
PC87UD11
C38CP50
2
1100/
3800
CH64 2300 2300 - - - PC73UD95V11CTF 8
PC87UD10
C44CP50
2
1100/
4400
Table 44. Fuse sizes for VACON
®
NX Liquid-Cooled (640—1100 V) inverters
Chas
sis
Type
I
th
[A]
DIN43620
"TTF" threaded end
"7X"
or size 83 with end
contacts
"TTQF" threaded
end size84 or
"PLAF" 2x84 with
end contacts
Fuse
I
n
[A]
Fuse
size
aR fuse part
nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
CH61 0170 170 DIN1 PC71UD13C400PA 2 PC71UD13C400TF 2 - - 400
CH61 0208 208 DIN1 PC71UD13C400PA 2 PC71UD13C400TF 2 - - 400
CH61 0261 261 DIN1 PC73UD13C500PA 2 PC73UD13C500TF 2 - - 500
CH62 0325 325 DIN3 PC73UD13C630PA 2 PC73UD13C630TF 2 - - 630
CH62 0385 385 DIN3 PC73UD11C800PA 2 PC73UD13C800TF 2 - - 800
CH62 0416 416 DIN3 PC73UD11C800PA 2 PC73UD13C800TF 2 - - 800
CH62 0460 460 DIN3 PC73UD10C900PA 2 PC73UD12C900TF 2- -900
CH62 0502 502 DIN3 PC73UD10C900PA 2 PC73UD12C900TF 2- -900
CH63 0590 590 DIN3 PC73UD13C630PA 4 PC83UD12C11CTF 2 - -
630/
1100
CH63 0650 650 DIN3 PC73UD13C630PA 4 PC83UD11C13CTF 2 - -
630/
1300
CH63 0750 750 DIN3 PC73UD11C800PA 4 PC83UD11C14CTF 2 - -
800/
1400
CH64 0820 820 DIN3 PC73UD11C800PA 4 PC73UD13C800TF 4
PC84UD13
C15CTQ
2
800/
1500
CH64 0920 920 DIN3 PC73UD10C900PA 4 PC73UD12C900TF 4
PC84UD12
C18CTQ
2
900/
1800
CH64 1030 1030 - - - PC83UD12C11CTF 4
PC84UD11
C20CTQ
2
1100/
2000
Table 43. Fuse sizes for VACON
®
NX Liquid-Cooled (450—800 V) inverters
Chas
sis
Type
I
th
[A]
DIN43620
"TTF" threaded end
"7X"
or size 83 with end
contacts
"TTQF" threaded
end size84 or
"PLAF" 2x84
with end
contacts
Fuse
I
n
[A]
Fuse
size
aR fuse
part nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
aR fuse
part nr.
Fuses
needed
per
drive
