X5 AC Drive User’s Manual X5 Parameter Summary Table
DPD00089A - vii - © 2009 Vacon Incorporated All Rights Reserved
860 PID Sleep Cfg text string 0 (disabled) 103
861 PID Sleep Lvl 0.00-100.00% 0.00% 103
862 PID Wake-up Lvl 0.00-100.00% 100.00% 103
863 Sleep Delay Time 0.0-300.0 sec 0.0 sec 103
864 Wake-up Delay 0.0-300.0 sec 0.0 sec 103
865 PID Feedback 0.00-100.00% Read-only 103
866 PID Reference 0.00-100.00% Read-only 103
867 PID User Units text string 0 (No) 103
880 FBus Read 1 0-65535 103 104
881 FBus Read 2 0-65535 104 104
882 FBus Read 3 0-65535 105 104
883 FBus Read 4 0-65535 107 104
884 FBus Read 5 0-65535 909 104
890 FBus Write 1 0-65535 907 104
891 FBus Write 2 0-65535 402 104
892 FBus Write 3 0-65535 403 104
893 FBus Write 4 0-65535 920 104
894 FBus Write 5 0-65535 921 104
900 SIO Protocol text string 0 (RTU N81) 104
901 SIO Baud Rate text string 2 (9600) 104
902 Comm Drop # 1-247 1 104
903 SIO Timer 0.0-60.0 sec 1.0 sec 104
904 SIO Cntl Word Bit 0-15 0x0000 105
905 Ext Ref Freq1 Min-Max Freq 0.0 Hz 105
906 Ext Ref Freq2 Min-Max Freq 0.0 Hz 105
907 Cntl Word 2 Bit 0-15 0x0000 105
908 Status Word Bit 0-15 Read-only 105
909 DI Status Bit 0-14 Read-only 106
910 Vin1 Status 0.00-100.00% Read-only 106
911 Cin Status 0.00-100.00% Read-only 106
912 Vin2 Status 0.00-100.00% Read-only 106
913 Output Status Bit 0-5 Read-only 106
914 Vmet Status 0.00-100.00% Read-only 106
915 Imet Status 0.00-100.00% Read-only 106
916 Infrared Baud text string 2 (9600) 106
917 FBus Port Config text string 1 (485 w/ctl) 107
920 SIO Vmet Level 0.00-100.00% 100.00% 107
921 SIO Imet Level 0.00-100.00% 100.00% 107
926 Status Word 2 Bit 0-2 Read-only 107
930 Seq Cntl 1 Bit 0-15 (hex control) 0x0000 108
931 Seq Cntl 2 Bit 0-15 (hex control) 0x0000 108
932 Seq Cntl 3 Bit 0-15 (hex control) 0x0000 108
933 Seq Cntl 4 Bit 0-15 (hex control) 0x0000 108
934 Seq Cntl 5 Bit 0-15 (hex control) 0x0000 108
935 Seq Cntl 6 Bit 0-15 (hex control) 0x0000 108
936 Seq Cntl 7 Bit 0-15 (hex control) 0x0000 108
937 Seq Cntl 8 Bit 0-15 (hex control) 0x0000 108
938 Seq Cntl 9 Bit 0-15 (hex control) 0x0000 108
939 Seq Cntl 10 Bit 0-15 (hex control) 0x0000 108
940 Seq Cntl 11 Bit 0-15 (hex control) 0x0000 108
941 Seq Cntl 12 Bit 0-15 (hex control) 0x0000 108
942 Seq Cntl 13 Bit 0-15 (hex control) 0x0000 108
No. Parameter Name Options Default User Setting See Page
= cannot change in Run
Bold type = Level 1 parameter
Note that all parameters can be addressed by adding 40000 to the parameter number. For example, parameter 201 (Input Mode) can be
addressed by Modbus address 40201.
