For proper grounding, make sure that the cable shield is between the
bracket and the device.
CAUTION!
7. Use the grounding point in the strain relief plate for equipotential bonding, where
applicable.
8. Reattach the strain relief cover plate.
9. Reattach each connector to the circuit board.
More information
‣
LED indicators (page 86)
‣
Connecting WMT700 (page 95)
4.6.1
Connector plate (optional)
If you are using the connector plate, not all figures in Connecting cables and grounding
(page 20) apply.
